Klímový kompresor Ford Focus MK2 1.6 TDCI 3M5H-19D629-SA

Použitie v nasledovných typoch áut:

Ford C-MAX 02.2007 -> today
Ford Focus C-MAX 10.2003 -> 03.2007
Ford Focus II (DA_) 11.2004 -> today
Ford Focus II Estate (DAW_) 11.2004 -> today
Ford Focus II Saloon (DA_) 04.2005 -> today

Mazda 3 (BK) 10.2003 -> 06.2009
Mazda 3 Saloon (BK) 06.2000 -> 06.2009

Volvo S40 II (MS) 01.2004 -> today
Volvo V50 (MW) 04.2004 -> today

Napísané može byť v nasledovných kombináciach:

Ford
3M5H19D629GA, 3M5H 19D629 GA, 3M5H-19D629-GA
3M5H19D629GC, 3M5H 19D629 GC, 3M5H-19D629-GC
3M5H19D629GD, 3M5H 19D629 GD, 3M5H-19D629-GD
3M5H19D629KC, 3M5H 19D629 KC, 3M5H-19D629-KC
3M5H19D629KD, 3M5H 19D629 KD, 3M5H-19D629-KD
3M5H19D629KE, 3M5H 19D629 KE, 3M5H-19D629-KE
3M5H19D629KF, 3M5H 19D629 KF, 3M5H-19D629-KF
3M5H19D629KG, 3M5H 19D629 KG, 3M5H-19D629-KG
3M5H19D629SA, 3M5H 19D629 SA, 3M5H-19D629-SA
3M5H19D629SB, 3M5H 19D629 SB, 3M5H-19D629-SB
3M5H19D629TA, 3M5H 19D629 TA, 3M5H-19D629-TA
31291882, 31 291 882, 31-291-882
31348213, 31 348 213, 31-348-213
36000271, 36 000 271, 36-000-271
36000986, 36 000 986, 36-000-986
36000990, 36 000 990, 36-000-990
36001870, 36 001 870, 36-001-870
1306784, 1 306 784, 1-306-784
1341233, 1 341 233, 1-341-233
1355809, 1 355 809, 1-355-809
1438877, 1 438 877, 1-438-877
1439594, 1 439 594, 1-439-594
1465439, 1 465 439, 1-465-439

Mazda
BBR461450, BBR4 61450, BBR4-61450
BP8F61450B, BP8F 61 450B, BP8F-61-450B
BP8F61450D, BP8F 61 450D, BP8F-61-450D
BP8F61450E, BP8F 61 450E, BP8F-61-450E

Volvo
1016001034, 10 160 01034, 10-160-01034
36000271, 3 600 027 1, 3-600-027-1
4065795, 4 065 795, 4-065-795
8603685, 8 603 685, 8-603-685

SD7V161077, SD7V16 1077, SD7V16-1077
SD7V161248, SD7V16 1248, SD7V16-1248
SD7V161255, SD7V16 1255, SD7V16-1255
SD7V161288, SD7V16 1288, SD7V16-1288
SD7V161293, SD7V16 1293, SD7V16-1293
SD7V161812, SD7V16 1812, SD7V16-1812
SD7V161841, SD7V16 1841, SD7V16-1841

Hella
8FK 351 316-071
8FK 351 113-451

**************************************************
Manufacturer Restriction: Sanden
Compressor ID: SD7V16
Number of Ribs: 6
Compressor Oil: PAG 46
Oil Fill Quantity: 200 ml
Pulleys: with v-ribbed belt pulley
Belt Pulley Ø: 119 mm
Port Type: PAD
Cylinder Head ID (Compressor): VRF / VRD
Voltage: 12 V
**************************************************
